The 6864 pendant light from the Haul range by MILAN ILUMINACION features a housing made from extruded aluminium tubing and a diffuser made from hand-blown opal glass. Finish: textured black paint (RAL 9005).
1 × DOB LED 7 W, 665 lm (95 lm/W), 2,700 K, CRI 90, 3-step MacAdam, beam angle 58°, driver on the LED board, no external transformer required, 230 V, dimmable with an LED-compatible phase-cut dimmer, energy efficiency class E, IP20 protection rating (for dry indoor use only), protection class I (with earth connection), height 210 mm, diameter 55 mm, maximum suspension height 3,000 mm.
Tested dimmers: Eltako EUD61NPN, dimmable 20–100 per cent; Casambi CBU-TED, dimmable 20–100 per cent.
Technical specifications
| Luminaire |
|---|
| Item number | 6864 | Luminaire type | pendant light |
| Family | Haul | EAN | 8435146968648 |
| Finish and material |
|---|
| Finish | textured black paint finish (RAL 9005) |
| Housing | Extruded aluminium tube | Diffuser | Hand-blown opal glass |
| Light |
|---|
| Light source | 1 × DOB LED 7 W | Luminous flux | 665 lm |
| Light colour | 2,700 K | Colour rendering | CRI 90 |
| Colour tolerance | 3-step MacAdam | Beam angle | 58° |
| Electrical |
|---|
| Rated voltage | 230 V |
| Dimmability | dimmable with an LED-compatible phase-cut dimmer |
| Energy efficiency class | E | Protection rating | IP20 |
| Protection class | I |
| Dimensions |
|---|
| Height | 210 mm | Diameter | 55 mm |
| Suspension | max. 3,000 mm |
| Packaging and dispatch |
|---|
| Number of cartons | 1 | Carton 1 | 31.5 × 11 × 10 cm |
| Shipping weight | 0.8 kg |
