The 6851 track spotlight from the Haul range by MILAN ILUMINACION has a housing made from extruded aluminium tubing. Finish: textured white (RAL 9016).
1 × DOB LED 7 W, 665 lm (95 lm/W), 2,700 K, CRI 90, 3-step MacAdam, beam angle 58°, driver on the LED board, no external transformer required, 230 V, dimmable with an LED-compatible phase-cut dimmer, energy efficiency class E, Adapter for single-phase track (GLOBAL), protection rating IP20 (for dry indoor use only), protection class I (with earth connection), rotates 300°, tilts 90°, height 172 mm, diameter 55 mm, length 127 mm.
Tested dimmers: Eltako EUD61NPN, dimmable 20–100 per cent; Casambi CBU-TED, dimmable 20–100 per cent.
Technical data
| Luminaire |
|---|
| Item number | 6851 | Luminaire type | track spotlight |
| Family | Haul | EAN | 8435146968518 |
| Design and material |
|---|
| Finish | textured white paint finish (RAL 9016) | Housing | Extruded aluminium tube |
| Light |
|---|
| Light source | 1 × DOB LED 7 W | Luminous flux | 665 lm |
| Light colour | 2,700 K | Colour rendering | CRI 90 |
| Colour tolerance | 3-step MacAdam | Beam angle | 58° |
| Electrical |
|---|
| Rated voltage | 230 V |
| Dimmability | dimmable with an LED-compatible phase-cut dimmer |
| Energy efficiency class | E | Ingress protection | IP20 |
| Protection class | I |
| track | Adapter for single-phase track (GLOBAL) |
| Motion |
|---|
| Movement | Rotates 300°, swivels 90° |
| Dimensions |
|---|
| Height | 172 mm | Diameter | 55 mm |
| Length | 127 mm |
| Packaging and dispatch |
|---|
| Number of cartons | 1 | Carton 1 | 31.5 × 11 × 10 cm |
| Shipping weight | 0.5 kg |
