The 6103 wall-mounted light from the Mini range by MILAN ILUMINACION has a die-cast aluminium housing and a diffuser made of hand-blown opal glass. Available in a range of finishes.
1 × G9 socket, 230 V, for LED bulbs up to 4.8 W; dimmability, colour rendering and energy efficiency class depend on the bulb used; protection rating IP20 (for dry indoor use only); protection class I (with earth connection); Height 151 mm, projection 45 mm, width 110 mm, ceiling rose 110 × 151 mm.
Not included: light source. Suitable bulbs are 2024 (G9 LED 4.7 W, 600 lm, 2,700 K, non-dimmable) and 2015 (G9 LED 4 W, 480 lm, 2,700 K, dimmable).
Technical specifications
| Luminaire |
|---|
| Item number | 6103 | Luminaire type | wall-mounted light |
| Range | Mini | EAN | 8435146961038 |
| Design and material |
|---|
| Design | Design as required | Housing | Die-cast aluminium |
| Diffuser | Hand-blown opal glass |
| Electrical |
|---|
| Socket | 1 × G9 | Rated voltage | 230 V |
| Max. power | 4.8 W | Dimmability | Depends on the light source |
| Colour rendering | Depends on the light source | Energy efficiency class | Depends on the light source |
| Protection rating | IP20 | Protection class | I |
| Dimensions |
|---|
| Height | 151 mm | Projection | 45 mm |
| Width | 110 mm | Canopy | 110 × 151 mm |
| Suitable light source (not included) |
|---|
| 2024 | G9 LED 4.7 W, 600 lm, 2,700 K, non-dimmable |
| 2015 | G9 LED 4 W, 480 lm, 2,700 K, dimmable |
| Packaging and dispatch |
|---|
| Number of boxes | 1 | Box 1 | 15.7 × 9.2 × 9.3 cm |
| Shipping weight | 0.4 kg |
